5g mobile tower
Self-Supporting Towers
A 5G mobile tower is a sophisticated and highly efficient structure designed to support the next generation of mobile telecommunications. Standing typically between 30 to 60 meters tall, these towers are essential for providing the ultra-fast, high-capacity connectivity that defines 5G technology. They play a crucial role in delivering improved data speeds, lower latency, and enhanced network reliability.
Constructed from high-strength materials such as galvanized steel or aluminum, 5G towers are engineered to withstand a wide range of environmental conditions, including high winds, heavy rain, and extreme temperatures. Their robust construction ensures longevity and minimal maintenance.
The foundation of a 5G mobile tower is a critical component for its stability and durability. It is typically anchored in a deep concrete base to support the significant height and weight of the structure. This foundation design ensures that the tower remains stable and secure under various environmental stresses.
Safety is a top priority in the design and installation of 5G towers. They are equipped with various safety features, including anti-climb panels and secure fencing at the base to prevent unauthorized access and potential accidents. Additionally, maintenance platforms and safety harness attachment points are included for technicians who need to perform regular inspections and upgrades.
5G towers are designed to support a wide range of antennas and advanced communication equipment. These include massive MIMO (multiple-input, multiple-output) antennas, which significantly enhance data throughput and network capacity. The elevation provided by the tower ensures optimal signal transmission and reception, minimizing interference and maximizing coverage.
| Product | 5g mobile tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | below 150 meters |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. Telecommunication tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
