gsm tower
Self-Supporting Towers
A GSM tower, also known as a cellular tower or mobile phone tower, is a structure designed to facilitate wireless communication for GSM (Global System for Mobile Communications) networks. These towers are typically made of steel and consist of various components, including antennas, transmitters, receivers, and signal processing equipment.
GSM towers play a crucial role in providing mobile phone coverage over a specific geographic area. They transmit and receive radio signals to and from mobile devices, allowing users to make calls, send text messages, and access data services.
Commonly ranging in height from around 50 to 200 feet, GSM towers are strategically placed to ensure optimal coverage and signal strength. The height of the tower helps in maximizing the range of the signal and reducing interference, thereby improving the quality of communication for users.
In urban areas, GSM towers are often clustered together to handle high call volumes and provide seamless coverage amid tall buildings and other obstacles. In rural areas, they may be spaced farther apart to cover larger areas with fewer users.
Overall, GSM towers are essential infrastructure for modern telecommunications, enabling widespread mobile connectivity and facilitating communication on a global scale.
| Product | gsm tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | 20 ft, 25 ft, 30 ft, 40 ft, 50 ft, 60 ft, 70 ft, 75 ft, 80 ft, 100 ft, 200 ft, 500 ft, etc. |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, Telecommunications Tower, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. Telecommunications Tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
