radio antenna tower
Self-Supporting Towers
A radio antenna tower is a specialized structure designed to support antennas for broadcasting and receiving radio frequencies. Typically constructed from steel for durability and stability, these towers can vary in height, often extending hundreds of feet into the air to maximize signal coverage and strength. They are essential for a wide range of applications, including broadcasting radio and television signals, supporting cellular network infrastructure, and facilitating amateur radio communications. Radio antenna towers can be self-supporting, guyed with tensioned cables for additional stability, or constructed as monopoles depending on location and structural requirements. Their design ensures they withstand environmental stresses such as wind and ice, making them crucial for continuous, reliable communication.
| Product | radio antenna tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | 20 ft, 25 ft, 30 ft, 40 ft, 50 ft, 60 ft, 70 ft, 75 ft, 80 ft, 100 ft, 200 ft, 500 ft, 600 ft, etc. |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, Telecommunications Tower, steel structures, and observation towers.Transmission tower design adheres to ASCE/SEI standards. Telecommunications Tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
If you need professional product quotations, technical & construction support, please email to us or submit the following sheet, we will contact you in 24 hours and pls check your emailbox. Your connection information will just be known by ourselves.
