television towers
Self-Supporting Towers
Television towers are tall structures specifically designed to support the antennas required for television broadcasting. These towers enable the transmission of television signals across large distances, overcoming geographical barriers to reach various audiences. Constructed predominantly from steel or reinforced concrete, television towers are built to endure environmental challenges like strong winds, ice, and lightning.
Typical heights of television towers can vary significantly depending on their location and the need for signal reach, with common heights ranging between 300 and 1500 feet. The taller the tower, the broader the coverage area, as height helps in avoiding signal blockages caused by the Earth’s curvature and other obstructions.
Additionally, television towers often feature a distinctive design, sometimes with observation decks and antennas mounted at various levels, and are usually equipped with red and white paint or lights to ensure visibility for aircraft safety.
| Product | television towers |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | 300 and 1500 feet |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, Telecommunications Tower, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. Telecommunications Tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
If you need professional product quotations, technical & construction support, please email to us or submit the following sheet, we will contact you in 24 hours and pls check your emailbox. Your connection information will just be known by ourselves.
