cell tower
Self-Supporting Towers
A cell tower, also known as a cell site, is a tall structure typically installed with antennas and other electronic communication equipment to facilitate wireless communication. These towers are a critical part of cellular networks, providing coverage for mobile phones and other wireless devices.
Cell towers are strategically placed to create a network of coverage areas, often referred to as “cells.” As mobile devices move within these cells, they connect to different towers to maintain a continuous signal. This enables uninterrupted communication and data transmission for users as they travel.
Cell towers are designed to support multiple users and carriers, allowing for the simultaneous transmission of voice, data, and other wireless services. They play a vital role in enabling mobile communication, supporting everything from phone calls and text messages to internet access and mobile applications.
| Product | cell tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | 20 ft, 25 ft, 30 ft, 40 ft, 50 ft, 60 ft, 70 ft, 75 ft, 80 ft, 100 ft, 200 ft, 500 ft, 600 ft, etc. |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, cell towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. cell tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
If you need professional product quotations, technical & construction support, please email to us or submit the following sheet, we will contact you in 24 hours and pls check your emailbox. Your connection information will just be known by ourselves.
