phone tower
Self-Supporting Towers
“Phone tower” is a colloquial term often used to refer to a cell tower or a mobile phone tower. These towers are essential components of modern telecommunications infrastructure, providing the framework for wireless communication networks. Typically, phone towers are equipped with antennas and other equipment necessary to facilitate the transmission and reception of mobile phone signals. They play a crucial role in enabling mobile phone users to make calls, send text messages, and access data services. These towers are strategically placed to ensure coverage across a specific area, and they are often designed to support multiple wireless carriers. Additionally, advancements in technology have led to the deployment of smaller, more discreet towers known as small cell towers to enhance coverage and capacity in urban and densely populated areas.
| Product | phone tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | 20 ft, 25 ft, 30 ft, 40 ft, 50 ft, 60 ft, 70 ft, 75 ft, 80 ft, 100 ft, 200 ft, 500 ft, 600 ft, etc. |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, phone towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. phone tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
