500kv electrical tower
Lattice Transmission Tower
A 500kV electrical tower, used for ultra-high voltage power transmission, plays a crucial role in the efficient and reliable delivery of electricity over long distances. Here are key aspects to consider when dealing with these structures:
Design and Specifications
- Height and Strength: 500kV towers are typically taller and stronger than lower voltage towers, often exceeding 100 feet in height, to ensure adequate ground clearance and safety distances.
- Structure Type: Lattice steel towers are common due to their strength and cost-effectiveness, although monopole designs might be used in urban or constrained areas.
- Conductor Configuration: These towers usually support multiple conductors arranged in various configurations (horizontal, vertical, delta) to manage electrical and mechanical loads effectively.
| Product | 500kv electrical tower |
| Shape | lattice |
| Material | Normally Q345B/A572, Minimum Yield Strength ≥ 345 N/mm² Q235B/A36, Minimum Yield Strength ≥ 235 N/mm². OR Q420 Q460 ASTM A572 GR65, GR50, SS400 |
| Electric Voltage | 500kv |
| Surface treatment | Hot dip galvanized Following ASTM A 123, BS729 or as client required. |
| connection | bolt connection |
| Standard | ISO 9001:2008 |
| Height: | below 60 meters |
| Surface treatment: | galvanization and color painted |
| Welding Standard | AWS (American Welding Society ) D 1.1 |
| Production Process | Raw material test → Cutting →Welding →Hole drilling →Dimension verify →sample assemble → surface clean→ Galvanization or powder coating ,painting →Recalibration →Packages |
| Packages | Packing with plastic paper, steel box or according to client’s request. |
Deshi Tower specializes in the design, manufacture, and construction support of transmission towers, communication towers, steel structures, and observation towers.
Transmission tower design adheres to ASCE/SEI standards. Telecommunication tower design follows ANSI/TIA-222 standards. We are not just manufacturers and suppliers, but also your technical support and partners.
